Description
Features:
- Small footprint
- Upgraded vacuum system and 3 vacuum cups
- Chain and lug drive ensuring a square box is formed
- Quick/Easy changeover
- Load on the fly / easy load hopper
- Maximum outside dimensions 16″ long x 14″ wide x 12″ high
- Minimum outside dimensions 6″long x 6″wide x 4″high
- Allen Bradley Micrologix 820 PLC
- Removable, 2″ heavy duty Caselocker CAC60 tape cartridge
- Calibrated scales for quick, easy width and height adjustments
Specifications:
Case Dimensions:
- Height: 4″-12″ (102 mm – 305 mm)
- Width: 6″-14″ (152 mm – 356 mm)
- Length: 6″-16″ (152 mm – 406 mm)
General:
- Air requirements: 14 SCFM at 85 psi
- Weight: 1100 lbs. (498.9 kg)
Electrical:
AC Voltage supply: Power Requirement: 110 VAC, single phase, 60 cycle, 8.0 Amps
Options:
- Casters
- Leg adjustments
- Box jam warning
- Low hopper warning
- No tape detection
- Spare parts kit
- Stainless steel
- Leveling pads
- Air dryer
- Mobile control station
- High speed upgrade
- NEMA 12, NEMA 4
