Features:

• Minimal operator training
• Improved tool-less change over
• Walk-in chain driven power hopper with hydraulic height adjustment mounted horizontally to ensure ensure that there is no weight on the front of the cases
• Quick/Easy changeover
• Load on the fly / easy load hopper
• Maximum outside dimensions 24″ long x 16″ wide x 20″ high
• Minimum outside dimensions 7″ long x 6″ wide x 4″ high
• Power hopper is fork truck accessible up to mid-point
• Bottom squeezer to compress major flaps together for increased cases integrity and squareness
• Pneumatic flap folders front and rear to eliminate chronic jamming
• Allen Bradley Micrologix 1000 PLC
• Control panel with remote coil cord SMC pneumatic with the latest valve and actuator technology
• Photocell case on demand system
• Calibrated scales for quick, easy width and height adjustments

Specifications:

Case Dimensions: (XL and XXL models available)

• Height: 4″-20″ (102 mm – 508 mm)
• Width: 6″-16″ (152 mm – 406 mm)
• Length: 7″-24″ (177 mm – 610 mm)

General:

• Air requirements: 14 SCFM at 85 psi
• Weight: 1000 lbs. (4.9 kg)

Electrical:

AC Voltage supply: Power Requirement: 110 VAC, single phase, 60 cycle, 8.0 Amps

Options:

• Casters
• Leg adjustments
• Box jam warning
• Low hopper warning
• No tape detection
• Spare parts kit
• Stainless steel
• Leveling pads
• Air dryer
• Mobile control station
• High speed upgrade
• NEMA 12, NEMA 4
