LX-600T / LX-600DT

Main Uses

  • Compact and versatile label applicator
  • Best suited for automatic tamp applications utilizing preprint labels
  • Designed to support dual tamp and corner wrap applications
  • Can print labels on both uniform and random runs of cases

Quick info

Description

Features :

  • Quality components – Allen Bradley PLC and SMC Pneumatics : improve uptime, readily available and proven throughout industry, familial to maintenance staff
  • Random stroke applicator (LX-600T) applies labels to random size cases within its reach, effective stroke length of 6-1/2 inches
  • Allen Bradley PLC controls with HMI touchscreen for ease of operator adjustments
  • Tool-less mounting stand turns labeler for standalone or easy conveyor integration
  • Customizable applicator pads
  • Fast, intuitive setup/minimal training required

Specifications:

Labeler :

  • Label width: 5-3/8″(136.525 mm) ; Min. Label Width: 1″(25.4 mm)
  • Label length: 14″(355.6 mm) ; Min. Label length: 3/4″(19.05 mm)
  • Outside diameter: 11-7/8″ (301.6 mm)
  • Core Diameter: 3″ (76.2mm), Optional 4″ (101.6mm) for label over 6″ (152.4mm) long

General :

  • Weight: 76 lbs. (17.3 kg) (including yolk)

Electrical :

  • AC Voltage supply: Power Requirement: 115-230 VAC, 5 Amps, 50/60 Hz

Air :

  • 45-60 PSI at ½ CFM while dispensing

Available Options:

  • Low label sensor with 3 color light pole
  • Dual tamp/Corner wrap applicator (Model: LX-600DT)
  • Incoming air dryer
  • Cleanable Vacuum filter
  • Spare parts kit
  • Various Grids and Chanbers
