Features:

• Able to process both void-filled and over stuffed cases at speeds exceeding 40% faster than the competition
• Minimum outside dimensions: 6″ long x 5-1/2″ wide x 3-1/2″ high
• Maximum outside dimensions: Infinite” long x 21-1/2″ wide x 24-1/2″ high
• Production rate capabilities of up to 15 cases per minute (Operator / process dependant )
• Pneumatic system is complete and includes a filter / regulator / lubricator
• Roller in-feed pack table included
• Leeson reducer and TEFC motor
• Machine accepts 2″ and 3″ cartridges
• New heavy duty side threading case locker

Specifications:

• Power Requirements: 110 volts, single phase, 60 cycle
• Operating Speed: Continuous belt drive; Standard: 115′ per minute (35.05 m/min). High  speed: 155′ per minute (47.24 m/min)
• Air requirements: 9 SCFM at 85 PSI
• Weight : 570 lbs. (258 kg.), uncrated

Case Capacity (with 2″ wide CaseLocker ST(TM) cartridge):

• Power Requirements: 110 volts, single phase, 60 cycle
• Operating Speed: Continuous belt drive; Standard: 115′ per minute (35.05 m/min). High speed: 155′ per minute (47.24 m/min)
• Air requirements: 9 SCFM at 85 PSI
• Weight : 570 lbs. (258 kg.), uncrated

Machine Dimensions:

• Length: 64-1/4″ (1632 mm)
• Width: 33-5/8″ (854 mm)
• Height: 59-7/8″ (1490 mm)

Reliable Performance – Warranty:

• 1 Year all components*
• 2 Years Gear Reducer
• 3 Years Cartridge*

*Moving and wear parts are not included. Other restrictions may apply. Consult your authorized distributor for details.
